How to Become a Site Manager on a National Grid Substation (SR163.11 v2)

Updated October 2026 for the SR163.11 version 2 appointment form

If you want to know how to become a site manager on a National Grid Electricity Transmission (NGET) substation, start with the job title, because it undersells the role. The SR163.11 Principal Contractor Site Manager (PCSM) is ultimately responsible for everything that happens on site, and must be on site at all times while work is under way. On a non-National Grid project, that level of responsibility would usually sit with a Construction Manager or Senior Site Agent, not a site manager.

National Grid has also issued version 2 of the SR163.11 Principal Contractor / Contractor Representative Appointment Form, and some of the prerequisites have changed. This guide covers:

  • what the PCSM role really involves
  • which NGET works and projects need a PCSM
  • how the role compares with roles on other construction sites
  • the full SR163.11 v2 prerequisites
  • the documents needed for appointment
  • how to get the right PCSM training

What is a Principal Contractor Site Manager (PCSM)?

The National Grid site manager role used to be known as TP144, then TP137.11 and TP163.11. It is now governed by SR163.11. The person in the role is called the Principal Contractor Representative (PC Rep) or Principal Contractor Site Manager (PCSM).

The PCSM is the Principal Contractor’s appointed duty holder on an NGET project. They discharge the Principal Contractor’s duties under CDM 2015, NG/ET/SR163 and the wider NGET Supplier Requirements. They do this on behalf of the organisation that holds the contract with National Grid.

Where is a PC Rep required?

The PC Rep requirement applies to all NGET capital plan works and projects undertaken within a CDM-controlled area. It applies whether the work is located within or outside the boundary of a substation, and it includes overhead line (OHL) works.

In practice, this means a PC Rep is needed for:

  • substation works, both inside the operational boundary and on adjacent compounds and land
  • overhead line projects, including tower, foundation and conductor works
  • cable routes, access roads, laydown areas and other works outside the substation fence
  • any other NGET capital plan work carried out within a CDM-controlled area

The role is not limited to “substation site managers”. Anyone managing NGET capital works away from a substation, such as on an OHL project, needs to meet the same SR163.11 requirement, unless your contract states otherwise.

The PC Rep must be on site at all times

The PC Rep must be on site at all times while work is taking place. The role cannot be covered remotely, by phone or by visiting the site occasionally. The PC Rep is the Principal Contractor’s presence on site and the person responsible for controlling the work as it happens.

This has practical consequences for Principal Contractors:

  • Cover must be planned. Holidays, sickness, training days and shift patterns all need an appropriately appointed PC Rep in place. Many PCs therefore appoint more than one PC Rep per project.
  • One PC Rep cannot spread across several active sites. Where work runs at the same time at different locations, such as several OHL work fronts or a substation and a remote compound, each needs suitable PC Rep cover.
  • Extended hours and weekend working need cover too. If work is taking place, the PC Rep needs to be there.
  • It shapes the site management structure. The PC Rep requirement should be built into the project resource plan from the start, not added later.

A PCSM is more like a Construction Manager or Senior Site Agent

On most construction sites, a site manager runs day-to-day activity. They report to a Site Agent, Senior Site Agent or Construction Manager, who carries overall responsibility for the site. On a National Grid site, the PCSM is that person. They are ultimately accountable for everything on site, including:

  • Safety and CDM compliance: acting as the Principal Contractor’s representative and making sure CDM 2015 duties are met.
  • High voltage risk: managing Impressed Voltage, earthing arrangements and work near live HV plant. They are often the Earthing Control Person as well.
  • Temporary Works: they are often the appointed Temporary Works Coordinator.
  • Environment and waste: ensuring legal compliance across the site.
  • Underground services: controlling excavation in and around a live substation.
  • Quality: making sure work meets NGET Supplier Requirements and Technical Specifications.
  • Subcontractors: managing every contractor and interface on site.
  • Emergency arrangements: including first aid, emergency response and incident reporting.
  • Documentation and assurance: keeping records that stand up to National Grid scrutiny.
 Typical construction siteNational Grid (SR163.11) site
Overall site responsibilityConstruction Manager / Senior Site AgentPCSM / PC Rep
Presence on siteVaries by role and contractOn site at all times while work is under way
Where it appliesProject by projectAll NGET capital plan works in a CDM-controlled area, inside or outside a substation, including OHL
Formal appointmentUsually internalSigned appointment form submitted to the NGET Client Representative
Live HV and Impressed Voltage riskRareCore part of the role
Minimum trainingSMSTS, First Aid, CSCS10 prerequisites under SR163.11 v2

This is why the SR163.11 prerequisites are so extensive. It also explains why the appointment must be signed off by a director or senior manager who confirms the individual is competent. Anyone moving from a general construction background should treat PCSM as a senior, accountable management role, not a sideways move from site manager.

Construction site manager vs National Grid PCSM: what’s the difference in training?

Traditional construction site manager requirements

A site manager on a typical construction project would usually need:

National Grid PCSM requirements (SR163.11 v2)

To be appointed as a PCSM on an NGET project, you must meet every minimum prerequisite on the v2 form. Copies of certificates must be included with the appointment form.

What’s new in SR163.11 version 2?

If you have been working to the old form, review your site managers against these changes:

  • CDM competence: an accredited certificate is now required. That means SMSTS and IOSH, or NEBOSH.
  • Waste management: a certified environmental and waste management course is now required.
  • HSG47: the course must now include the live substation module and be refreshed every 3 years.
  • Asbestos: certified Asbestos Awareness training is a new requirement.
  • NGET Supplier Requirements: the training requirement has been enhanced.
  • NGET Technical Specifications: evidence of training on these is a new requirement.

SR163.11 v2 minimum prerequisites for National Grid site managers

1. Impressed Voltage training

You must understand the causes and consequences of Impressed Voltage. The NG Competent Person and Person IV CBT/eLearning does not satisfy this requirement. The employing organisation must provide accredited IV training. Many Principal Contractors also want the PCSM to be the Earthing Control Person (ECP), so they will need to understand the PC’s own IV processes.

2. Competent Person accreditation (NSI6 and NSI8)

You must hold valid Competent Person accreditation. The Principal Contractor must hold and monitor the expiry dates.

3. CDM competence: SMSTS and IOSH, or NEBOSH (new in v2)

You need an accredited certificate showing CDM competence. This is either (a) SMSTS and IOSH, or (b) NEBOSH.

4. Temporary Works training

You must understand procedural control of Temporary Works to British Standards. The minimum is a certified TW awareness course. The PCSM is often also the Temporary Works Coordinator, which needs the CITB course and a formal appointment.

5. Environmental and waste management training (certified course new in v2)

You must understand UK environmental and waste management legislation. The minimum is a certified waste management course.

6. HSG47 in a live HV substation (live substation module and 3-year refresh new in v2)

You need an accredited HSG47 Avoiding Danger from Underground Services course that includes the live substation module. It must be refreshed every 3 years.

7. Asbestos Awareness (new in v2)

You need certified Asbestos Awareness training.

8. National Grid Supplier Requirements training (enhanced in v2)

You need evidence of training on NGET Supplier Requirement Procedures, plus confirmation that you have access to them. The training should cover at least SR106, SR107, SR135, SR141, SR163, SR183, SR188, SR234 and SR241. It should also cover the latest Engineering and Safety Bulletins, NG Safety Rules and Documents, and NSI6 and NSI8.

9. NGET Technical Specifications (new in v2)

You need evidence of training on the Technical Specifications relevant to your role and discipline, plus confirmation that you have access to them. We are currently developing training to support this new requirement.

10. Principal Contractor Management Systems

You need evidence of training on the PC’s safety, quality, environmental and sustainability management systems, plus confirmation that you have access to them.

Documents needed for SR163.11 appointment

Submit the following with each nomination:

  • Completed appointment form, signed by both the appointee and a director or senior manager of the organisation directly contracted with NGET
  • CV
  • Competency Management System matrix for the role
  • The individual’s Competency Management System record
  • EUSR registration number

The form also asks for a detailed Statement of Competence, which has two parts:

  • Knowledge: training, institution, dates and expiry.
  • Experience: NG projects, other Electricity Supply Industry work and other relevant work, with dates, client, location, voltage, role and responsibilities.

Completed forms go to the NGET Client Representative for the project.

Why does a PC Rep usually need First Aid at Work training?

First Aid at Work is not listed on the SR163.11 v2 form. Even so, most Principal Contractors still expect their PC Rep / PCSM to hold a current 3 Day First Aid at Work certificate, and many make it a condition of appointment. Here’s why.

The PC Rep owns the site’s emergency arrangements. Under CDM 2015, the Principal Contractor must plan, manage and monitor the construction phase, including arrangements for emergencies. Employers also have a duty under the Health and Safety (First-Aid) Regulations 1981 to provide adequate first aid cover. As the person ultimately responsible for the site, the PC Rep is expected to understand those arrangements in practice, not just on paper.

The PC Rep is always on site. Because the PC Rep must be on site at all times while work is under way, they are the one person who can be relied on to be present. That makes them a natural first aider and helps keep cover in place.

NGET sites are often remote and secure. Many substations and overhead line routes are in rural locations, so emergency services can take longer to arrive. Substations are also access-controlled, so emergency responders may need to be met and escorted to the casualty. In the meantime, the first response on site has to be competent.

Site teams can be small. At some stages of a project, and on many OHL work fronts, only a handful of people may be on site. A designated first aider may be absent, on leave or working elsewhere.

The risks are higher than on a typical site. NGET work brings electrical, Impressed Voltage, excavation, lifting and working-at-height risks. A PC Rep with first aid training can respond in the first critical minutes and manage the scene. They also understand what first aid cover the site actually needs.

Principal Contractor and client expectations. Many PCs include First Aid at Work in their competency matrix for the PC Rep role. That matrix is one of the mandatory documents submitted with the SR163.11 appointment, so a missing certificate can still hold up the nomination.

First aid knowledge also helps the PC Rep in other parts of the role:

  • carrying out first aid needs assessments
  • checking that subcontractors provide enough first aiders
  • making sure first aid kits, defibrillators (AEDs) and emergency contact details are in place
  • leading incident response and reporting

A First Aid at Work certificate is valid for 3 years, so make sure it stays in date. Like other expiry dates, it should be tracked in the Principal Contractor’s Competency Management System.

Other tickets often requested: a CSCS Black Card and other sector-specific qualifications relevant to the role.

Why is there a shortage of National Grid site managers?

There are four main reasons:

  • It’s a senior role: the PCSM carries the responsibility of a Construction Manager or Senior Site Agent, so the pool of suitable people is smaller.
  • They must be on site at all times: every active NGET project, including OHL and works outside the substation boundary, needs PC Rep cover. Holidays, sickness and multiple work fronts all add to demand.
  • The training is extensive, and SR163.11 v2 adds to it.
  • IR35: these roles are treated as inside IR35, which reduces the number of experienced contractors available.

As a result, Tier 1 contractors are investing heavily in upskilling and mentoring their own people into PCSM roles.

PCSM training with Pragmatic Consulting

We help Principal Contractors and individuals meet the SR163.11 requirements through training, assessments, quizzes, interviews and scenario-led problem solving. See our SR163.11 Principal Contractor Site Manager (PCSM) Training or call 01926 674340 to speak to the team.

FAQs

What is SR163.11?

SR163.11 is the National Grid Electricity Transmission appointment form and process for Principal Contractor and Contractor Representatives (site managers) on NGET projects. It replaced TP163.11 and TP144.

Is a National Grid site manager the same as a normal site manager?

No. Despite the title, the SR163.11 PCSM is ultimately responsible for everything on site, including safety, HV risk, temporary works, environment, quality and subcontractors. On non-National Grid projects, that responsibility usually sits with a Construction Manager or Senior Site Agent.

Does the PC Rep have to be on site all the time?

Yes. The PC Rep must be on site at all times while work is under way. Principal Contractors need to plan cover for leave, sickness and multiple work fronts.

Does SR163.11 apply to overhead line and off-substation works?

Yes. It applies to all NGET capital plan works and projects undertaken within a CDM-controlled area, whether located within or outside the boundary of a substation, including overhead line works, unless you have anything else written into your contract.

If the work is in a CDM area outside the NG Safety Rules, why do we still need an SR163.11 PC Rep?

Because that is exactly when the PC Rep matters most. When NGET hands an area over as a CDM-controlled area, it is no longer controlled under the NG Safety Rules. Control passes to the Principal Contractor, and the PC Rep is the person who exercises that control on site, under CDM 2015. SR163.11 is how NGET gets assurance that the person in charge of that area is competent.

The hazards do not stop at the CDM boundary either. Work in a CDM area is often next to live HV plant or overhead lines, and Impressed Voltage, underground services and the interface with Safety Rules areas all still have to be managed. That is why SR163.11 applies to all NGET capital plan works in a CDM-controlled area, inside or outside a substation, including overhead line works. Unless you have anything else written into your contract.

What changed in SR163.11 version 2?

Version 2 adds SMSTS and IOSH (or NEBOSH) for CDM competence, a certified waste management course, the HSG47 live substation module with a 3-year refresh, Asbestos Awareness, training on NGET Technical Specifications, and enhanced Supplier Requirements training.

Does the National Grid IV eLearning count for SR163.11?

No. The NG Competent Person and Person IV CBT does not satisfy the requirement. Accredited Impressed Voltage training is needed.

Is First Aid required for a National Grid site manager?

It is not listed on the SR163.11 v2 form, but most Principal Contractors still require it. The PC Rep is responsible for the site’s emergency arrangements and is always on site, often on remote, secure locations with small teams and higher-risk work. First Aid at Work is commonly included in the PC’s competency matrix for the role.

How long does it take to become a National Grid site manager?

It depends on what training and experiences you already hold. Contact us and we can review your current certificates against the v2 requirements.
